Topcam IPC-TOP-SW2A
Ai Smart IP Cam 4MP POE 2 Way Audio SD Card Human Detection Alarm System Full Color 24/7
| Order | Specification | |
| 1 | System
Structure |
Embedded RTOS design, dual core;32 bits DSP,pure hardware compression, watch dog,8MB FLASH,512Mb DDR3;; |
| 2 | Sensor | 4MP 1/3″ CMOS,0.001Lux@F1.2(color),0Lux(IR ON);integrate IR-CUT drive, support linkage control between Sensor &IR-CUT& photosensitive& LED fill light, support day/night switch; |
| 3 | Video Process | H.265+/H.265/H.264 video coding, support dual stream, AVI format; code stream 500~8000kbps adjustable; support PAL and NTSC |
| 4 | Frame Rates | 4MP and 3MP@20 FPS |
| 5 | Image Output | Main stream:2560×1440，2304×1296,1920×1080,1280×960,1280×720; |
| Code stream:D1,800×448,640×480,640×360,352×228; | ||
| 6 | Audio interface | 1channel input,support mic or pickup input;1channel output, support headset or amplifier play |
| 7 | Audio coding | G.711 CODEC standard, support dual voice talkback, audio and video synchronization; |
| 8 | Network Interface | 1*RJ45 Ethernet interface,10/100M self-adaption,8KV anti-static electric capacity;support RTSP/DHCP/NTP, GB/T28181,compatible ONVIF and so on network protocols; |
| 9 | LED Passive Interface | 2* IR LED control output interface,1*IRCUT interface, support linkage control between IR-CUT and image. |
| 10 | Mine-protected | Power supply, network comprehensive lightning protection, through the ITU-T, K.21-2008, IEC61000-4-2/IEC61000-4-5 and other lightning protection standards testing |
| 11 | Reset | Support for tail-end reset keys |
| 12 | Business Functions | Configure by WEB, OSD(on screen display),real-time video transmission, motion detection and IO alarm linkage ,center prompt and picture pop-up after IO alarm; support remote surveillance client software(Seetong);support mobile monitoring(iPhone, Android), support “Seetong” cloud service. |
| 13 | Power Supply | DC12V power input interface,1.284mW power consumption, front end power input, light protection,anti-static,anti-inverse connect, support 18V turn off voltage protection; |
| 14 | Size and weight | size :38×38×10.6mm, net weight 8g, without housing PCBA,38 size single structure; |
| 15 | Work Conditions | -40℃～+85℃ |
| 16 | Optional Functions | E(POE cable power supply)Extended interface(IO,IO,ACT,、White light PWM 、Infrared PWM); |
