Features
• 3 wireless antennas are designed to support independent Blue-tooth antennas for better Blue-tooth performance.
• Netflix compliant (subject to Netflix/operator certification).
• Compatible with comprehensive content including Netflix, Amazon Prime Video, Disney+, You-Tube.
• Get all the top apps and games on Google Play.
• Voice search and navigation via Google Assistant.
• Easily cast your favorite movies, music, and more to TV with Chromecast built-in.
• System upgrading via USB, GOTA.
• Optional Android TV standard Launcher.
• Optional multiple compatible industrial designs.
• Support software, industrial design and accessories customization.
Specifications
Basic Parameters
SoC: Amlogic S905Y4-B
CPU: ARM Quad 64-bit Cortex-A35
GPU: ARM Mali-G31 MP2GPU
OpenGL ES3.2,Vulkan1.1 andOpenCL2.0
DRAM: DDR4 2GB
Flash: eMMC 32GB
DRM: Widevine L1
HDR: HDR 10, HLG, HDR10+
OS: Androidâ„¢ 12
Resolution: Up to 4Kp60
Codecs
Video Codes:
• AV1 MP-10@L5.1 up to 4K*2K@60fps
• VP9 Profile-2 up to 4K*2K@60fps
• H.265/HEVC MP-10@L5.1 up to4K*2K@60fps
• H.264/AVC HP@L5.1 up to 4K*2K@30fps
• MPEG-2 MP/HL up to 1080P@60fps
• Other codecs on request
• AAC-LC & AAC-HE
• MPEG-1 Layers 1, 2, 3
• Optional Dolby Digital, Dolby Digital Plus, • Other codecs on request
Container: *.mkv,*.mpg,*.mpeg, *.dat, *.avi, *.mov,*.mp3 and *.ogg
Power External 12.0V/1.0 A
Power Consumption: 12W Max
IO Port
DC in 12V-1A
HD-MI 2.1 with HDCP
USB2.0 Port *2
S/P DIF
Analog AV CVBS + L/R Audio (3.5mm Jack)
Network Ethernet Lan 10/100
WIFI 2.4/5 MHZ
Blue-tooth 5.2
Operation temperature:0~40℃
Operation Humidity：5%~85% Non-condensing
Material: Plastic
Proposed Accessory: Power Adapter, HD-MI Cable, Remote Control
